Chison ECO6 is a powerful, portable color Doppler ultrasound machine designed for high-quality imaging and versatile clinical applications. With advanced imaging technology and a user-friendly interface, it’s ideal for clinics, hospitals, and mobile diagnostic services.
The Chison ECO6 delivers excellent image quality with its advanced technologies like speckle reduction imaging (SRI), tissue harmonic imaging, and compound imaging. These features allow for clear visualization of structures, making it suitable for a wide range of applications including abdominal, OB/GYN, vascular, cardiac, MSK, and small parts examinations.
Its lightweight and compact design make it highly portable, while the long-lasting battery and built-in trolley support both in-clinic and bedside scanning. The system includes a high-resolution LED monitor, multiple probe options, and customizable measurement packages for various specialties. It also features efficient patient data management and USB export functionality.
Built for performance and durability, the ECO6 offers an excellent balance of affordability and functionality. It helps medical professionals deliver accurate diagnostics, especially in settings where space, mobility, and speed are essential.
| Category | Specification |
|---|---|
| Display | 12″ high-resolution LED (1024×768), rotatable 0–30° |
| Dimensions | 335 × 155 × 350 mm (L×W×H); Weight: ~6.5 kg (no probe) |
| Power | AC 100–240 V 50–60 Hz; Li-ion battery, ≈2.5 hours |
| Probes | 2 active ports; compatible with convex, linear, micro-convex, phased-array, rectal probes |
| Imaging Modes | B, B/B, 4B, B/M, M, CFM, CPA, DPD, PW, B-steer, Triplex; CW Doppler & TDI optional |
| Advanced Imaging | Compound Imaging (MCI), Speckle Reduction (SRA), Tissue Harmonic Imaging (THI), i-Image, Super Needle, Auto IMT |
| Workflow & Interface | Dual probe holder, backlit keyboard, 8 TGC sliders, one-key workflows |
| Data & Connectivity | 8 GB memory (expandable to 500 GB), USB×3, VGA, video output, Ethernet, footswitch, DICOM 3.0 optional |
| Applications | Abdomen, OB/GYN, Cardiac (with option), Urology, Vascular, Small parts, MSK, Nerve, Pediatrics, etc. |
| Operating Conditions | 10–40 °C, 30–75% RH; Storage: –25–55 °C, ≤95% RH |
| Compliance & Standards | IEC 60601‑1, 60601‑2‑37, IEC 60601‑1‑2 EMC, IEC 60601‑1‑4, ISO 10993 |
| File Handling | Cine storage (AVI), image review layouts, archive and reporting system |
