Advanced LED technology, 1000 test per hour, high-performance, fully automated clinical chemistry analyzer designed for medium to large integrated laboratories. With fast throughput, high precision, and intelligent workflow management, it is ideal for routine and advanced biochemical testing in modern diagnostics.
The Maccura C1000 offers accurate and high-speed analysis for a wide range of clinical chemistry tests, including liver and kidney function, cardiac markers, glucose, lipids, enzymes, and more. It supports continuous loading of samples and reagents, allowing uninterrupted operations in busy lab environments.
Equipped with a large touchscreen interface, the C1000 features automatic calibration, reagent management, clot detection, and quality control systems to ensure precision and reliability. Its built-in barcode scanner and LIS connectivity streamline workflow and enhance sample traceability.
With a robust build and user-friendly design, Maccura C1000 helps labs handle high test volumes while maintaining consistent accuracy. It's the perfect solution for hospitals, diagnostic centers, and research labs that require scalable, dependable, and efficient chemistry analysis.
| Specification Category | Details |
|---|---|
| System Function | Single-module colorimetric & ISE detection |
| Colorimetric Detection Speed | 1000 tests/hour |
| ISE Detection Speed | 600 tests/hour |
| Reaction Principle | Photoelectric colorimetry & ion selective electrode method |
| Reagent System | Complete system with Maccura machine, reagents, QC, and calibration support |
| Third-party Reagent Support | Yes |
| HbA1c Whole Blood Testing Support | Yes |
| Reagent Positions | 65 dual reagent positions (130 total) |
| Automatic Reagent Loading | Supported |
| Reagent Bottle Type | Integrated bottles |
| Reagent Refrigeration Temp | Refrigerated |
| Probe System | Sample probe accuracy: 20–80 µL |
| Reagent probe accuracy: 1.0–25.0 µL | |
| Reagent Volume Range | 10.0 µL to 150.0 µL, adjustable in 0.5 µL steps |
| Mixing System | Non-contact ultrasonic mixing |
| Reaction Volume Range | 35 µL to 185 µL |
| Incubation System | Constant temperature circulating water bath at 37.0 ± 0.3 °C |
| Temperature Range | 15°C to 30°C |
| Temperature Accuracy | ±0.10°C |
| Cassette Quantity | 35 |
| Optical System | Absorbance linear range: 0 to 3 Abs |
| Wavelength range: 340 nm – 800 nm, 13 wavelengths | |
| Light source: LED, lifespan > 20,000 hours | |
| Equipment Weight | Approximately 500 kg |
| Overall Dimensions | 1315 mm (H) × 1211 mm (W) × 969 mm (D) |
| Computer System | Windows 10 or higher compatible operating systems |
| Environmental Requirements | Temperature: 15°C – 30°C, Humidity: 40% – 85% |
| Power Supply | Voltage: 220 V ±22 V AC, 50 Hz frequency |
